10.12 Menu 11: General drive set-up
Table 10-22 Menu 11 parameters: single line descriptions
Parameter Range Default Setting Update Rate
11.01 Pr 61 set-up {71}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.02 Pr 62 set-up {72}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.03 Pr 63 set-up {73}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.04 Pr 64 set-up {74}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.05 Pr 65 set-up {75}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.06 Pr 66 set-up {76}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.07 Pr 67 set-up {77}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.08 Pr 68 set-up {78}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.09 Pr 69
set-up {79}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.10 Pr 70 set-up {80}Pr 1.00 to Pr 21.51 Pr 0.00 B
11.11 Not used
11.12 Not used
11.13 Not used
11.14 Not used
11.15 Not used
11.16 Not used
11.17 Not used
11.18 Not used
11.19 Not used
11.20 Not used
11.21 Customer defined scaling {24} 0.000 to 9.999 1.000 B
11.22 Parameter displayed at power up OFF(0) or On(1) OFF(0) N/A
11.23 Serial comms address {44} 0 to 247 1 B
11.24 Modbus RTU / user serial mode 0 to 4 1 B
11.25 Serial comms baud rate {43}
2.4(0), 4.8(1), 9.6(2),
19.2(3), 38.4(4)
19.2(3) B
11.26 Silent period extension 0 to 250 ms 2 B
11.27 Drive configuration {05}
AI.AV(0), AV.Pr(1), AI.Pr(2),
Pr(3), PAd(4), E.Pot(5),
tor(6), Pid(7), HVAC(8)
Eur:AI.AV(0)
USA: PAd (4)
Edit mode exit
11.28 Not used
11.29 Software version {45} 0.00 to 99.99 N/A
11.30 User security code {25} 0 to 999 0 B
11.31 Not used
11.32 Maximum heavy duty drive current rating 0.00 to 290.00 A N/A
11.33 Drive voltage rating 0 to 3
N/A
11.34 Software sub-version 0 to 99
N/A
11.35 DSP software version 0.0 to 9.9
N/A
11.36 Not used
11.37 Not used
11.38 Not used
11.39 Not used
11.40 Not used
11.41 Status mode timeout 0 to 250 s 240 B
11.42 Parameter copying {28}
no(0), rEAd(1), Prog(2),
boot(3)
no(0) Edit mode exit
11.43 Load defaults {29} no(0), Eur(1), USA(2) no(0) Edit mode exit
11.44 Security status {10} L1(0), L2(1), L3(2), LoC(3) L1(0) Edit mode exit
11.45 Select motor 2 parameters OFF(0) or On(1) OFF(0) B
11.46 Defaults previously loaded 0 to 2 0 BW
11.47 PLC ladder program enable {59} 0 to 2 0 BR
11.48 PLC ladder program status {60} -128 to 127
BW
11.49 Not used
11.50 PLC ladder program maximum scan time 0 to 65535 ms User program
