Emerson 2401 - Terminal T5-7 Digital Input 1-3 State; Relay 1 State (Terminals T21 and T23); Terminal T5-7 Digital Input 1-3 Invert; Relay 1 Invert (Terminals T21 and T23)

Menu 15
I/O options
Introduction
Parameter
x.00
Parameter
description format
Keypad and
display
Serial
communications
CT Modbus
RTU
PLC Ladder
programming
CTSoft Menu 0
Advanced parameter
descriptions
178 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 9
0: OFF Inactive
1: On Active
Terminals T5 to T7 are three programmable digital inputs.
These parameters indicate the state of the digital input terminals.
If an external trip is required, then one of the terminals should be programmed to control the external trip parameter (Pr 10.32), with the invert set to
On(1) so that the terminal must be made active for the drive not to trip.
The digital inputs are set up in positive logic. This logic cannot be changed.
0: OFF De-energized
1: On Energized
This parameter indicates the state of the relay.
Setting these parameters to On(1) causes the input sense to the destination parameter to be inverted.
Setting this parameter to On(1) causes the relay sense to be inverted.
15.04 Terminal T5 digital input 1 state
15.05 Terminal T6 digital input 2 state
15.06 Terminal T7 digital input 3 state
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background write
15.07 Relay 1 state (Terminals T21 and T23)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background write
15.08 to 15.13 Unused parameters
15.14 Terminal T5 digital input 1 invert
15.15 Terminal T6 digital input 2 invert
15.16 Terminal T7 digital input 3 invert
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate Background read
15.17 Relay 1 invert (terminals T21 and T23)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate Background read
15.18 Unused parameter
NOTE
