9 Menu 0
Table 9-1 Menu 0 parameters: single line descriptions
Par Description
Default
Corresponding extended
menu parameter
Setting
Eur USA
01 Minimum set speed (Hz) 0.0 Pr 1.07
02 Maximum set speed (Hz) 50.0 60.0 Pr 1.06
03 Acceleration rate (s/100Hz) 5.0 33.0 Pr 2.11
04 Deceleration rate (s/100Hz) 10.0 33.0 Pr 2.21
05 Drive configuration AI.AV PAd Pr 11.27
06 Motor rated current (A) Drive rating Pr 5.07
07 Motor rated speed (rpm) 1500 1800 Pr 5.08
08 Motor rated voltage (V)
230/400/575/
690
230/460/575/
690
Pr 5.09
09 Motor power factor (cos ϕ)0.85Pr 5.10
10 Parameter access L1 Pr 11.44
11 Start/Stop logic select 0 4 Pr 6.04
12 Brake controller enable diS Pr 12.41
15 Jog reference (Hz) 1.5 Pr 1.05
16 Analog input 1 mode (mA) 4-.20 Pr 7.06
17 Enable negative preset speeds OFF (0) Pr 1.10
18 Preset speed 1 (Hz) 0.0 Pr 1.21
19 Preset speed 2 (Hz) 0.0 Pr 1.22
20 Preset speed 3 (Hz) 0.0 Pr 1.23
21 Preset speed 4 (Hz) 0.0 Pr 1.24
22 Load display units Ld Pr 4.21
23 Speed display units Fr Pr 5.34
24 Customer defined scaling 1.000 Pr 11.21
25 User security code 0 Pr 11.30
27 Power up keypad reference 0 Pr 1.51
28 Parameter copying no Pr 11.42
29 Load defaults no Pr 11.43
30 Ramp mode select 1 Pr 2.04
31 Stop mode select 1 Pr 6.01
32 Dynamic V to f select OFF (0) Pr 5.13
33 Catch a spinning motor select 0 Pr 6.09
34 Terminal B7 mode select dig Pr 8.35
35 Digital output control (terminal B3) n=0 Pr 8.41
36 Analog output control (terminal B1) Fr Pr 7.33
37 Maximum switching frequency (kHz) 3 Pr 5.18
38 Autotune 0 Pr 5.12
39 Motor rated frequency (Hz) 50.0 60.0 Pr 5.06
40 Number of motor poles Auto Pr 5.11
41 Voltage mode select Ur I Fd Pr 5.14
42 Low frequency voltage boost (%) 3.0 1.0 Pr 5.15
43 Serial comms baud rate 19.2 Pr 11.25
44 Serial comms address 1 Pr 11.23
45 Software version
Pr 11.29
46 Brake release current threshold (%) 50 Pr 12.42
47 Brake apply current threshold (%) 10 Pr 12.43
48 Brake release frequency (Hz) 1.0 Pr 12.44
49 Brake apply frequency (Hz) 2.0 Pr 12.45
50 Pre-brake release delay (s) 1.0 Pr 12.46
51 Post brake release delay (s) 1.0 Pr 12.47
52 *Solutions Module dependant
Pr 15.03
53 *Solutions Module dependant
Pr 15.04
54 *Solutions Module dependant
Pr 15.06
55 Last trip
Pr 10.20
