Commander SK Advanced User Guide 179
Issue Number: 9
0: OFF Real time clock normal operation
1: On Real time clock + 1 hour
The real time clock is not available on SM-I/O Lite.
This word is used to determine the status of the digital I/O by reading one parameter.
Pr 15.20 contains a binary value 'xx'. This binary value is determined by the state of Pr 15.04 to Pr 15.07. So for example, if all terminals were active
the value displayed in Pr 15.20 would be the sum of the binary values shown in the table, i.e. 120.
Destination parameters define the parameter each of the programmable inputs is to control. Only parameters that are not protected can be controlled
by the programmable digital inputs. If a non-valid parameter is programmed, the digital input is not routed anywhere.
This parameter defines the parameter to be represented by the status relay. Only valid parameters can be selected as a source for the relay output. If
a non-valid parameter is programmed, then the relay will remain in the last known state.
15.19 Real time clock daylight saving mode
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate Background read
15.20 Digital I/O read word
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1
Range 0 to 120
Update rate Background write
Binary value for xx Digital I/O
1
2
4
8 Terminal T5
16 Terminal T6
32 Terminal T7
64 Terminals T21 & T23
128
15.21 to 15.23 Unused parameters
15.24 Terminal T5 digital input 1 destination
15.25 Terminal T6 digital input 2 destination
15.26 Terminal T7 digital input 3 destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
15.27 Terminal T21/T23 relay 1 source
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Read on drive reset
15.28 to 15.29 Unused parameter
