10.8 Menu 7: Analog inputs and outputs
Table 10-9 Menu 7 parameters: single line descriptions
Parameter Range Default Setting Update Rate
7.01 Analog input 1 level (terminal T2) {94) 0.0 to 100.0%
5 ms
7.02 Analog input 2 level (terminal T4) {95} 0.0 to 100.0%
5 ms
7.03 Not used
7.04 Heatsink temperature -128 to 127 °C B
7.05 Power circuit temperature 2 -128 to 127 °C
B
7.06 Analog input 1 mode (terminal T2) {16}
0 -20(0), 20-0(1), 4-20(2),
20-4(3), 4-.20(4), 20-.4(5),
VoLt(6)
4-.20(4) B
7.07 Not used
7.08 Analog input 1 scaling 0.000 to 4.000 1.000 B
7.09 Analog input 1 invert OFF(0) or On(1) OFF(0) 5 ms
7.10 Analog input 1 destination Pr 0.00 to Pr 21.51 Pr 1.36 Drive reset
7.11 Analog input 2 mode (terminal T4) VoLt(0) or dig(1) VoLt(0) B
7.12 Analog input 2 scaling 0.000 to 4.000 1.000 B
7.13 Analog input 2 invert OFF(0) or On(1) OFF(0) 5 ms
7.14 Analog input 2 destination Pr 0.00 to Pr 21.51 Pr 1.37 Drive reset
7.15 Not used
7.16 Not used
7.17 Not used
7.18 Not used
7.19 Analog output source Pr 0.00 to Pr 21.51 Pr 2.01 Drive reset
7.20 Analog output scaling 0.000 to 4.000 1.000 21 ms
7.21 Not used
7.22 Not used
7.23 Not used
7.24 Not used
7.25 Not used
7.26 Not used
7.27 Not used
7.28 Current loop loss indicator OFF(0) or On(1) 5 ms
7.29 Not used
7.30 Analog input 1 offset ±100.0% 0.0 5 ms
7.31 Analog input 2 offset ±100.0% 0.0 5 ms
7.32 Not used
7.33 Analog output control (Terminal B1) {36}
Fr(0), Ld(1), A(2), Por(3),
USEr(4)
Fr(0) Edit mode exit
7.34 IGBT junction temperature ±200 °C
B
7.35 Drive thermal protection accumulator 0 to 100%
B
7.36 Power circuit temperature 3 -128 to 127 °C
B
