Commander SK Advanced User Guide 129
Issue Number: 9 www.controltechniques.com
Indicates the drive is not in the trip state. If Pr 10.36 is On(1) and an auto-reset is being used, this bit is not cleared until all auto-resets have been
attempted and the next trip occurs.
Indicates that the inverter output is active.
This bit is set to On(1) when the absolute value of the ramp output is at or below the threshold programmed into Pr 3.05.
In bipolar mode (Pr 1.10 = On) this parameter is the same as zero speed (Pr 10.03).
In unipolar mode, this parameter is set if the absolute value of the ramp output is at or below minimum speed + 0.5Hz. Minimum speed is defined by
Pr 1.07.
The parameter is only set if the drive is running.
These flags are set by the speed detector in menu 3. These flags are only set if the drive is running.
See Pr 3.06 on page 58.
Indicates that the modulus of the active current is greater or equal to the rated active current as defined in menu 4.
10.01 Drive ok
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background
10.02 Drive active
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background
10.03 Zero speed
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background
10.04 Running at or below minimum speed
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background
10.05 Below set speed
10.06 At speed
10.07 Above set speed
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background
10.08 Load reached
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Update rate Background
