Emerson 2402 - Reactive Current (Motor Magnetising Current); Overriding Current Limit; Motor Overload Accumulator; Percentage Load;Load Display Units

Menu 4 Introduction
Parameter
x.00
Parameter
description format
Keypad and
display
Serial
communications
CT Modbus
RTU
PLC Ladder
programming
CTSoft Menu 0
Advanced parameter
descriptions
70 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 9
This parameter is proportional to the length of the vector in the x axis of the reference frame and is equivalent to the reactive current (magnetising
current) in each output phase in amps.
This parameter gives an indication of the internal CURRENT_LIMIT_MAX as defined above.
This parameter gives a continuous indication of modelled motor temperature as a percentage of the trip level.
When this parameter reaches 75% (and the load is above 105%), the drive will flash 'OVL.d' on the display to indicate that the motor temperature is
excessive and the motor current should be reduced to stop the drive from tripping on 'It.AC’
When this parameter reaches 100%, the drive will give an 'It.AC’ trip or apply a restriction on the current limit (see Pr 4.16 on page 68).
The level of the accumulator is given by:
Also see Pr 4.15 on page 68.
This parameter indicates the drive loading as a percentage of rated active current, where the 100% rated active current is Pr 5.07 x Pr 5.10.
Therefore:
A positive value in this parameter indicates motoring load and a negative value indicates a regenerating load.
0: Ld Value of Pr 4.20 displayed.
1: A Value of Pr 4.01 displayed.
This parameter defines whether the load indication in the display status mode displays percentage load or output current
4.17 Reactive current (motor magnetising current)
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 121 1 1
Range ±DRIVE_CURRENT_MAX A
Update rate Background
4.18 Overriding current limit
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111 1 1 1
Range 0 to TORQUE_PROD_CURRENT_MAX %
Update rate Background
4.19 Motor overload accumulator
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 1 1
Range 0.0 to 100.0%
Update rate Background
4.20 Percentage load
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111 1 1
Range ±USER_CURRENT_MAX%
Update rate Background
4.21 Load display units {22}
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 111
Range Ld(0) or A(1)
Default Ld(0)
Update rate Background
4.22 to 4.23 Unused parameters
Pr 4.19
Pr 4.01
2
1e
-t Pr 4.15⁄
–()
Pr 5.07 1.05×()
2
-------------------------------------------------------------
⎝⎠
⎜⎟
⎛⎞
100%×=
Pr 4.20
Motor active current (Pr 4.02)
Motor rated current (Pr 5.07) Power factor (Pr 5.10)×
----------------------------------------------------------------------------------------------------------------------------------------------------
100%×=
