Menu 15
I/O options
Introduction
Parameter
x.00
Parameter
description format
Keypad and
display
Serial
communications
CT Modbus
RTU
PLC Ladder
programming
CTSoft Menu 0
Advanced parameter
descriptions
184 Commander SK Advanced User Guide
www.controltechniques.com Issue Number: 9
This parameter shows the percentage of the encoder reference level being used.
The encoder reference is scaled by this parameter, before being sent to the encoder reference destination.
This parameter may be routed to any non-protected drive parameter.
After a modification to this parameter, the destination is only changed when a reset is performed.
Setting this Bit parameter to On will reset the drive encoder revolution counter (Pr 15.53) and drive encoder position (Pr 15.54) to zero.
Please refer to the SM-I/O Lite/ SM-I/O Timer user guide for further information on the SM-I/O Lite and SM-I/O Timer.
15.57 Drive encoder reference level
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1
Range -100% to +100%
Update rate Background write
15.58 Drive encoder reference scaling
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3 111
Range 0.000 to 4.000
Default 1.000
Update rate Background read
15.59 Drive encoder reference destination
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Pr 0.00 to Pr 21.51
Default Pr 0.00
Update rate Drive read on reset
15.60 Encoder reset
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11
Range OFF(0) or On(1)
Default OFF(0)
Update rate
Encoder only: 13ms
All I/O routed: 30ms
