Commander SK Advanced User Guide 95
Issue Number: 9 www.controltechniques.com
The energy meters indicate the energy supplied from and into the drive in kWh and MWh. Pr 6.24 and Pr 6.25 give an accumulated value of power
used.
The energy meters are reset and held at zero when Pr 6.17 = On.
This parameter gives an instantaneous read out of the cost/hour of running the drive. This requires Pr 6.16 to be set up correctly.
Provides a means of disabling the drive from a programmable input. In order that the drive does not always require a separate enable terminal this
parameter is automatically set to On(1) if a drive terminal is not programmed as an enable terminal. A change from 0 to 1 causes a drive reset if the
drive is tripped (see Pr 6.14 on page 93). When a terminal is set to control this parameter the drive terminal always has over riding control.
This parameter is not designed to be used with the Solutions Modules.
Digital inputs connected to limit switches should be routed to these parameters if stopping is required at a limit. The drive will respond in 5ms and stop
the motor using the currently selected ramp rate. The limit switches are direction dependant so that the motor can rotate in a direction that allows the
system to move away from the limit switch.
Pre-ramp reference > 0Hz Forward limit switch active
Pre-ramp reference < 0Hz Reverse limit switch active
Pre-ramp reference = 0Hz Both limit switches active
6.25 Energy meter: kWh
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21 1 1 1
Range ±99.99 kWh
Update rate Background
6.26 Running cost
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range ±3200 currency/hour
Update rate Background
6.27 to 6.28 Unused parameters
6.29 Hardware enable
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range OFF(0) or On(1)
Default OFF(0)
Update rate 2 ms
6.30 Sequencing bit: Run forward
6.31 Sequencing bit: Jog forward
6.32 Sequencing bit: Run reverse
6.33 Sequencing bit: Forward/reverse
6.34 Sequencing bit: Run
6.35 Forward limit switch
6.36 Reverse limit switch
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range OFF(0) or On(1)
Default OFF(0)
Update rate 2 ms
