Emerson CSI 2140 Quick Start Guide

Option Description
F3 Intentionally blank.
F4 Set Display Units Set the default display units for the measurement values and plots.
F5 Comm Setup Set the communication options to connect the analyzer to AMS Machinery
Manager. You can also set up the Bluetooth functionality.
F6 Program Manager Update the programs, add new programs, delete unused programs, or
change the splash screen. A password is required to delete programs.
F7 Analyze or Adv.
Analyze
Collect data using predefined measurements called Analysis Experts, or
create your own measurements in Manual Analyze.
F8 Route Collect data using a route created in AMS Machinery Manager. You cannot
create or modify routes on the analyzer.
F9 Balance Balance a machine. Balance is an optional program that you load onto the
analyzer.
F10 Basic Laser Align
or Adv. Laser Align
Align machines. The Basic Laser Alignment Application comes with
analyzers that have the wireless option. The Advanced Laser Alignment
Application is an optional program that you can load onto the analyzer
and has more functions than the Basic application.
F11 Adv. Transient Collect large, unbroken time waveforms similar to a digital recorder.
Advanced Transient is an optional program that you load onto the
analyzer.
F12 ODS/Modal Collect cross channel data for animated analysis of a machine. ODS/Modal
is an optional program that you load onto the analyzer.
ALT2 keys
Option Description
F1 Version View the versions of the firmware and programs installed on your analyzer.
F2 General Setup Modify settings for the analyzer screen, keys, and print functionality.
F3 Set Time Set the time and date in the analyzer.
F4 Memory Utility View information about the internal memory.
F5 Battery Utility View information about the battery pack.
F6 View Error Log View information about any errors the firmware generated.
F7 Connect For
Printing
Connect to AMS Machinery Manager to print files or screen captures.
F8 Intentionally blank.
F9 Intentionally blank.
F10 Intentionally blank.
F11 Intentionally blank.
F12 Intentionally blank.
Touchscreen
The touchscreen and function keys let you access the menu options and
enter text. If the touchscreen does not respond accurately, calibrate the
touchscreen.
March 2016 Quick Start Guide
MHM-97430 Rev 4 11
