3410 Series Gas Ultrasonic Meters Operations Manual Section 6: Archive logs
3-9000-777 Rev E January 2018
Hourly log 93
PrevDayMacro2*: Macro
bit 31
bit 30
bit 29
bit 28
bit 27
bit 26
bit 25
bit 24
bit 23
bit 22
bits 21-19
bit 18
bit 17
bit 16
bit 15-10
bit 9
bit 8
bit7
bit 6
bit 5
bit 4
bit 3
bits 4-0
(unused)
IsMeasSndSpdRange
IsAvgSoundVelRangeErr
IsMeterVelAboveMaxLmt
IsHardFailedA
IsHardFailedB
IsHardFailedC
IsHardFailedD
(unused)
IsSNRTooLow
(unused)
IsPressureInvalid
IsTemperatureInvalid
IsAnyLogFull
(unused)
IsBlockageDetected
IsReverseFlowDetected
IsLiquidDetected
IsAbnormalProfileDetected
IsReverseFlowDetected
IsSndVelCompErr
AreGasPropertiesInvalidInUse
(unused)
Paths A-B, Dual-path meters
Paths A-D, 4-path meters
SndVelA
SndVelB
SndVelC
SndVelD
Flow-Gated
FlowVelA
FlowVelB
FlowVelC
FlowVelD
Flow-Gated
AvgFlow Flow-Gated
(Percent of good batch
signals)
PctGoodA1, PctGoodA2
PctGoodB1, PctGoodB2,
PctGoodC1, PctGoodC2,
PctGoodD1, PctGoodD2
Paths A1-B1, A2-B2 Dual-path meters
Paths C1-D1, C2-D2 4-path meters
QFlow Flow-Gated
QBase Flow-Gated
PosVolFlow Snapshot
NegVolFlow Snapshot
PosVolBase Snapshot
NegVolBase Snapshot
PosEnergy Totalize
NegEnergy Totalize
CompAvgMeterSndVel Snapshot
Table 6-2 Hourly log action type
Data point Log action
