56 Flow calibration
Section 5: Calibrate and configure the meter 3410 Series Gas Ultrasonic Meters Operations Manual
January 2018 3-9000-777 Rev E
– Edge gated, active low
Figure 5-7 Gating configuration parameter Edge gated, active low
– State gated, active high
Figure 5-8 Gating configuration parameter State gated, active high
– State gated, active low
Figure 5-9 Gating configuration parameter State gated, active low
A Microsoft Excel® file is generated and the calibration log report can be saved or appended to
an existing file.
High
Low
Calibration Start
Calibration Stop
High
Low
Calibration Start Calibration Stop
High
Low
Calibration Start Calibration Stop
