46 Wet calibration piece-wise linearization
Section 5: Calibrate and configure the meter 3410 Series Gas Ultrasonic Meters Operations Manual
January 2018 3-9000-777 Rev E
1. Select
Piece-wise linear from the Calibration|Meter Factors menu.
2. Click the
Add button below the table to add a new calibration point to the bottom of the
table. You can add a maximum of 12 points. The calibration points must be entered
from the highest flow rate to the lowest flow rate.
3. Click
Write to apply the calibration parameters to the meter.
Table 5-3 Data Points for Piece-Wise linearization calibration
Daniel MeterLink
Display Name
Data Points, Options and Guidelines
Forward Flow Rate Data points affected:
• FwdFlwRate1…FwdFltRate12
Options:
• Enter a value (m
3
/h or ft
3
/h) within the range [0, 200000 m
3
/h].
Guidelines:
• The flow rates must be entered from highest to lowest.
Forward Meter Factor Data points affected:
• FwdMtrFctr1…FwdMtrFctr12
Options:
• Enter a value (dimensionless) within the range [0.95,1.05].
Reverse Flow Rate Data points affected:
• RevFlwRate1…RevFltRate12
Options:
• Enter a value (m
3
/h or ft
3
/h) within the range [0, 200000 m
3
/h].
Guidelines:
• The flow rates must be entered from highest to lowest.
Reverse Meter Factor Data points affected:
• RevMtrFctr1…RevMtrFctr12
Options:
• Enter a value (dimensionless) within the range [0.95,1.05].
