3410 Series Gas Ultrasonic Meters Operations Manual Section 5: Calibrate and configure the meter
3-9000-777 Rev E January 2018
Gas properties 75
NOctaneInUse data points according to the component ID (C
6
PlusGCComponentID) as listed in
Tabl e 5 -1 1 below:
For example, if the
C
6
PlusGC mole percentage is 1% and its component ID is 110, then 60% of the
C
6
+ mole percentage (0.60x1%=0.60%) is added to NHexaneInUse, 30% (0.30x1%=0.30%) is
added to
NHeptaneInUse, and 10% (0.10x1%=0.10%) is added to NOctaneInUse.
The GC-reported NeoPentane component (
NeoPentaneGC) quantity is added to the IsoPentane
component (
IsoPentaneInUse).
The validity of the “In-Use” gas property data is readable via the
AreGasPropertiesInvalidInUse
data point where TRUE(1) indicates invalid data and FALSE(0) indicates valid data. The validity of
the “In-Use” gas property data is a function of the validity of the selected source data. If the
source data is selected as Fixed, then the “In-Use” gas property data is valid (since the fixed data
is assumed to be valid). If the source data is selected as Live - GC, then the “In-Use” gas property
data is valid only if the GC-read gas property data is valid.
Optional gas chromatograph interface
The Daniel 3410 Series Gas Ultrasonic Flow Meter can optionally interface with any Daniel gas
chromatograph (GC) that supports the SIM 2251 mode to read gas property data (such as for
AGA8, AGA10, energy rate, mass rate, and/or 3412 or 3411 profile correction calculations).
The following table lists the Gas Chromatograph SIM registers polled by the meter. Also refer to
Daniel Engineering Specification Part Number ES-17128-005 Rev. B.
Table 5-11 C
6
+ breakdown to standard components by component ID
C
6
+ Component ID
(
C
6
PlusGCComponentID)
Percentage to
NHexaneInUse
Percentage to
NHeptaneInUse
Percentage to
NOctaneInUse
108
47.466 35.340 17.194
109
50.000 50.000 0.000
110
60.000 30.000 10.000
111
57.143 28.572 14.285
The gas chromatograph interface is an optional feature that requires a valid GC feature key (see
Section 3.1.2
).
