17.9 REMOTE HOLIDAY MODE (ixF=HdF)
It is used to force the holiday mode.
17.10 REMOTE ONOFF (ixF=onF)
It is used to switch ON and OFF the device remotely.
17.11 LIGHT OUTPUT (ixF=LiG)
It is used to control the light output.
17.12 CHANGE CONFIGURATION (ixF=Lnt)
It is used to change the controller configuration.
17.13 MOTION SENSOR DETECTOR (ixF=EMt)
It is used to connect an X-MOD motion sensor. Please note that motion sensor can be connected only to the
HOTKEY port, so digital input 2 must be properly configured.
18. ALARM SIGNALLING
Label
Cause
Outputs
P1
P1 probe failure
Compressor output according to Con e CoF
P2
P2 probe failure
Depends on the relative function
P3
P3 probe failure
Depends on the relative function
P4
P4 probe failure
Depends on the relative function
HA
High temperature alarm
Outputs unchanged
LA
Low temperature alarm
Outputs unchanged
H2
Second high temperature alarm
Outputs unchanged
L2
Second low temperature alarm
Outputs unchanged
dA
Open door alarm
Compressor and fan follows par. odC
EA
Warning external alarm
Outputs unchanged
CA
Lock external alarm
Outputs disabled
EE
Internal memory alarm
Outputs unchanged
rtC
Real time clock error
Clock parameters are not configured
rtF
Real time clocl failure
Clock not present or clock circuit damaged
18.1 ALARM RECOVERY
Probe alarms P1, P2, P3 and P4 are activated some seconds after detecting a fault condition in the relative
probe. These alarms are automatically reset some seconds after the relative probe restarts normal operations.
Always check the connections (probe – device terminals) before replacing the probe. Temperature alarms HA,
LA, H2 and L2 are automatically reset as soon as the temperature is within the normal working range. It is
possible to reset the “EE” alarm by pressing any button.
The alarms EA, CA and dA are automatically reset as soon as the relative digital input is disabled.
The internal buzzer can be muted by touching any area of the display and only if parameter tbA=Y.
19. SERIAL COMMUNICATION
The device supports different baudrates (par. bAU). Please check the serial network
to adapt them according to the other devices. The XJ485CX serial interface is
required to convert the TTL output into an RS485 signal.
