FB2100 Flow Computer Instruction Manual
D301783X012
November 2023
44 Installation
3. Pick up the battery and carefully ease it into the battery compartment with the
writing on the battery facing out and the connectors on the upper right-hand side.
Nothing (including the strap) can be behind the battery.
Figure 2-31. Easing Battery Pack into Compartment
4. Carefully push the battery under the solar regulator (if present) and against the
back of the compartment, now strap it in tightly by pulling the ends of the strap.
Figure 2-32. Battery Pack Attached to Compartment
