Operation and Display Panel
Liebert
®
GXT4
™
User Manual 22
3.2 Control Buttons
The four control buttons on the front of the operation and display panel are:
• ESC
•Up
•Down
•Enter
Figure 3-1 shows the buttons’ locations; their descriptions and functions are shown in Table 3-2.
3.3 LCD
The LCD panel shows the UPS status and enables changes to the UPS settings by assisting in navigating
through the Liebert GXT4’s menu (see 3.4 - Menu Structure).
Table 3-2 Control buttons
Control Buttons Description
ESC Button
Pressing this button returns to the previous menu or aborts any change in the input data field
before confirming.
Up Button
Pressing this button can move the cursor up or increase the value displayed in the input data
field. When a menu is displayed on several screens, pressing the button can scroll up.
Down Button
Pressing this button can move the cursor down or decrease the value displayed in the input data
field. When a menu is displayed on several screens, pressing the button can scroll down.
Enter Button Pressing this button can enter the next level menu or confirm the parameter setting value.
