Label
DescriptionProLink II ProLink III
Field Communi-
cator
Primary Variable Source (Primary
Variable)
PV
The transmitter sends the primary
variable (PV) in the configured
measurement units in each burst
(e.g., 14.0 g/sec, 13.5 g/sec,
12.0 g/sec).
PV current & % of
range
Primary Variable
(Percent Range/
Current)
% range/current
The transmitter sends the PV’s per-
cent of range and the PV’s actual
mA level in each burst (e.g., 25%,
11.0 mA).
Dynamic vars & PV
current
Process Variables/
Current
Process variables/
current
The transmitter sends PV, SV, TV,
and QV values in measurement
units and the PV’s actual milliamp
reading in each burst (e.g.,
50 g/sec, 23 °C, 50 g/sec,
0.0023 g/cm3, 11.8 mA).
Transmitter vars Transmitter varia-
bles
Fld dev var
The transmitter sends four user-
specified process variables in each
burst.
3. Ensure that the burst output variables are set appropriately.
• If you set Burst Mode Output to send four user-specified variables, set the four
process variables to be sent in each burst.
• If you set Burst Mode Output to any other option, ensure that the HART variables
are set as desired.
Configure HART variables (PV, SV, TV, QV)
Display
Not available
ProLink II ProLink > Configuration > Variable Mapping
ProLink III Device Tools > Configuration > Communications > Communications (HART)
Field Communicator Configure > Manual Setup > Inputs/Outputs > Variable Mapping
Overview
The HART variables are a set of four variables predefined for HART use. The HART variables
include the Primary Variable (PV), Secondary Variable (SV), Tertiary Variable (TV), and
Quaternary Variable (QV). You can assign specific process variables to the HART variables,
and then use standard HART methods to read or broadcast the assigned process data.
Integrate the meter with the control system
Configuration and Use Manual 105
