6 Integrate the meter with the control
system
Topics covered in this chapter:
•
Configure the transmitter channels
•
Configure the mA output
•
Configure the frequency output
•
Configure the discrete output
•
Configure events
•
Configure digital communications
6.1 Configure the transmitter channels
Display OFF-LINE MAINT > OFF-LINE CONFG > IO > CH B
ProLink II ProLink > Configuration > Frequency/Discrete Output
ProLink III Device Tools > Configuration > I/O > Channels
Field Communicator Configure > Manual Setup > Inputs/Outputs > Channels > Channel B
Overview
You can configure Channel B on your transmitter to operate as a frequency output or a
discrete output. The channel configuration must match the wiring at the transmitter
terminals.
Prerequisites
To avoid causing process errors:
• Configure the channels before configuring the outputs.
• Before changing the channel configuration, ensure that all control loops affected by
the channel are under manual control.
Procedure
Set Channel B as desired.
Option Description
Frequency output
Channel B will operate as a frequency output.
Discrete output
Channel B will operate as a discrete output.
