Need help? If an error message appears:
• Verify the Modbus address of the transmitter.
• Ensure that you have specified the correct COM port.
• Check the physical connection between the PC and the transmitter.
• Increase or decrease resistance.
• For long-distance communication, or if noise from an external source interferes with the
signal, install 120-Ω ½-W terminating resistors in parallel with the output at both ends of
the communication segment.
• Ensure that there is no concurrent Modbus communication to the transmitter.
B.3 Menu maps for ProLink II
Main menuFigure B-9:
File
Preferences
• Use External Temperature
• Enable Inventory Totals Reset
• Enable External Pressure Compensation
• Copper RTD
Installed options
Load from Xmtr to File
Save to Xmtr from File
License
Connect to Device
Connect to Densitometer/
Viscometer
Disconnect
View Connection
Additional configuration options
Using ProLink II with the transmitter
Configuration and Use Manual 247
