Tip
Usually, but not always, the black lead is RS-485/A and the red lead is RS-485/B.
Connection to transmitter terminalsFigure B-7:
A. PC
B.
Signal converter
C. Transmitter, with wiring compartment and power supply compartment opened
Note
This figure shows a serial port connection. USB connections are also supported.
3. To connect over the RS-485 network:
a.
Attach the leads from the signal converter to any point on the network.
b. Add resistance as necessary.
Using ProLink II with the transmitter
Configuration and Use Manual 245
