Options for Pressure Measurement Unit (continued)Table 4-13:
Unit description
Label
Display ProLink II ProLink III Field Communica-
tor
Millimeters water @ 68 °F
mmH2O
mm Water @ 68°F
mm Water @ 68°F mmH2O
Millimeters mercury @ 0 °C
mmHG
mm Mercury @ 0°C
mm Mercury @ 0°C mmHg
Inches mercury @ 0 °C
INHG
In Mercury @ 0°C
In Mercury @ 0°C inHG
Pounds per square inch
PSI PSI PSI psi
Bar
BAR bar bar bar
Millibar
mBAR millibar millibar mbar
Grams per square centimeter
G/SCM g/cm2 g/cm2 g/Sqcm
Kilograms per square centime-
ter
KG/SCM kg/cm2 kg/cm2 kg/Sqcm
Pascals
PA pascals pascals Pa
Kilopascals
KPA Kilopascals Kilopascals kPa
Megapascals
MPA megapascals Megapascals MPa
Torr @ 0 °C
TORR
Torr @ 0°C
Torr @ 0°C torr
Atmospheres
ATM atms atms atms
