Service Tools menu: VariablesFigure D-16:
On-Line Menu >
3 Service Tools >
2 Variables
Process Variables
1 Mass Flow Rate
2 Volume Flow Rate *
3 Density
4 Temperature
Mapped Variables
1 PV Mass Flow Rate
2 SV Mass Flow Rate
3 TV Mass Flow Rate
4 QV Mass Flow Rate
1
3
5
Totalizer Control
1 All Totalizers
2 Mass
3 Volume *
4 CM Volume at Reference Temperature
5 CM Net Mass ***
6 CM Net Volume ***
7 Temp Corrected Volume (PM) **
8 Custody Transfer ****
All Totalizers
1 Start Totalizers
2 Stop Totalizers
3 Reset All Totals
4 Mass Total
5 Volume Total *
1
2
Mass
1 Mass Flow Rate
2 Mass Total
3 Mass Inventory
4 Reset Total
Volume *
1 Volume Flow Rate
2 Volume Total
3 Volume Inventory
4 Reset Total
3
Variable Summary
Mass Flow Rate
Volume Flow Rate *
Density
External Variables
1 External Temperature
2 External Pressure
4
2
* If Volume Flow Type = GSV, GSV variables
are displayed
.
** Displayed only if petroleum measurement is
enabled on your transmitter. Menu numbers
are adjusted as required.
*** Displayed only if concentration measurement
is enabled on your transmitter. Menu
numbers are adjusted as required.
**** Displayed only if the Weights & Measures
application is enabled on your transmitter.
Additional
options
Using the Field Communicator with the transmitter
Configuration and Use Manual 337
To Next Page
