Service Tools menu: Variables (continued)Figure D-17:
Outputs
1 mA Output (MA0)
2 Frequency Output
On-Line Menu >
3 Service Tools >
2 Variables
Variables (PM) *
1 Density at Reference
Temperature
2 Average Observed Density
3 Volume Flow at Reference
Temperature
4 Average Observed
Temperature
5 CTL
Variables (CM) **
1 Standard Volume Flow Rate
2 Standard Net Volume Flow
Rate
3 Net Mass Flow Rate
4 Density at Reference
5 Concentration
6 Density (Fixed SG Units)
6
8
7
Frequency Output
1 Present Freq Gauge
2 Present Freq Output
1
mA Output
1 Present MAO Gauge
2 PV MAO
3 PV % Range
2
* Displayed only if petroleum measurement is enabled
on your transmitter
. Menu numbers are adjusted as
required.
** Displayed only if concentration measurement is
enabled on your transmitter. Menu numbers are
adjusted as required.
