Service Tools menu: MaintenanceFigure D-18:
On-Line Menu >
3 Service Tools >
4 Maintenance
Routine Maintenance
1 Trim mA Output
2 Meter Verification *
1
Zero Calibration
1 Mass Flow Rate
2 Volume Flow Rate
3 Zero Time
4 Zero Value
5 Standard Deviation
6 Perform Auto Zero
7 Restore Factory Zero
Density Calibration
1 Mass Flow Rate
2 Density
3 Dens Pt1 (Air)
4 Dens Pt2 (Water)
5 Dens Pt3 T-Series
6 Dens Pt4 T-Series
7 Flowing Dens (FD)
2
Temperature Calibration
1 Temperature
2 Temp Cal Factor
4
3
Meter Verification **
1 Run Meter Verification
2 View Test Results
3 Schedule Meter
Verification
2
* Displayed only if meter verification
is enabled
.
** Displayed only if Smart Meter
Verification is enabled. For earlier
versions, the Meter Verification
Method is launched.
Additional
1 Core Processor Input
Voltage
2 Board Temperature
3 Power On Time
8
Modbus Data
1 Read Modbus Data
2 Write Modbus Data
6
5
Diagnostic Variables
1 Sensor Model
2 Drive Gain
3 LPO Amplitude
4 RPO Amplitude
5 Tube Frequency
6 Live Zero
7 Fld Verification Zero
8 Additional
Using the Field Communicator with the transmitter
Configuration and Use Manual 339
