Emerson Micro Motion Configuration And Use Manual

Procedure
Set Digital Communications Fault Action as desired.
The default setting is None.
Restrictions
• If mA Output Fault Action is set to None, Digital Communications Faut Action should also be set to None. If
you do not, the output will not report actual process data, and this may result in measurement
errors or unintended consequences for your process.
• If you set Digital Communications Fault Action to NAN, you cannot set mA Output Fault Action to None. If
you try to do this, the transmitter will not accept the configuration.
6.7.1 Options for Digital Communications Fault Action
Options for Digital Communications Fault ActionTable 6-11:
Label
DescriptionProLink III Field Communicator
Upscale Upscale • Process variable values indicate that the value is great-
er than the upper sensor limit.
Downscale Downscale • Process variable values indicate that the value is lower
than the lower sensor limit.
Zero IntZero-All 0 • Density is reported as 0.
• Temperature is reported as 0 °C, or the equivalent if
other units are used (e.g., 32 °F).
• Drive gain is reported as measured.
Not a Number Not-a-Number • Process variables are reported as IEEE NAN.
• Drive gain is reported as measured.
• Modbus scaled integers are reported as Max Int.
None None (default) • All process variables are reported as measured.
Integrate the meter with the control system
Configuration and Use Manual 97

Emerson Micro Motion Specifications

General

Category	Measuring Instruments
Manufacturer	Emerson
Brand	Micro Motion
Type	Coriolis Flow Meter
Output	4-20 mA, HART, Foundation Fieldbus, Profibus, Modbus
Power Supply	24 V DC
Material	Stainless Steel, Hastelloy
Process Connection	Flanged, Threaded
Certifications	ATEX, IECEx, CSA, SIL
Pressure Rating	Varies by model; up to 10, 000 psi (690 bar)
Temperature Range	Varies by model; -400 to 750°F (-240 to 400°C)
