B.3 Access and use the display menu system
The display menu system is used to perform various configuration, administrative, and
maintenance tasks.
Tip
The display menu system does not provide complete configuration, administrative, or maintenance
functions. For complete transmitter management, you must use another communications tool.
Prerequisites
To access the display menu system, operator access to either the Off-Line menu or the
Alert menu must be enabled. To access the complete menu system, operator access must
be enabled for both the Off-Line menu and the Alert menu.
Procedure
1. At the transmitter display, activate the Scroll and Select optical switches
simultaneously until the display changes.
You will enter the Off-Line menu at any of several locations, depending on several
factors.
• If an alert is active and access to the Alert menu is enabled, you will see SEE
ALARM.
• If no alert is active, you will see OFF-LINE MAINT.
2. If CODE? appears on the display when you make a choice, enter the value that is
configured for Off-Line Password.
a. With the cursor flashing on the first digit, activate Scroll until the correct digit is
displayed, then activate Select.
b. Repeat this process for the second, third, and fourth digits.
Tip
If you do not know the correct value for Off-Line Password, wait 30 seconds. The password
screen will time out automatically and you will be returned to the previous screen.
3. Use the Scroll and Select optical switches to navigate to your destination in the
display menu system.
• Use Scroll to move through a list of options.
• Use Select to choose the current option.
4. If Scroll flashes on the display, activate the Scroll optical switch, then the Select optical
switch, and then the Scroll optical switch again.
The display will prompt you through this sequence. The Scroll-Select-Scroll sequence is
designed to guard against accidental activation of the off-line menu. It is not
designed as a security measure.
5. To exit a display menu and return to a higher-level menu:
Using the transmitter display
