Page #165 background image
2. Observe and record data for both the left pickoff and the right pickoff, over an
appropriate period of time, under a variety of process conditions.
10.24 Check for internal electrical problems
Shorts between sensor terminals or between the sensor terminals and the sensor case can
cause the sensor to stop working.
Possible causes and recommended actions for electrical shortsTable 10-9:
Possible cause Recommended action
Faulty cable Replace the cable.
Shorts to the housing created by trapped or damaged wires Contact Micro Motion.
Loose wires or connectors Contact Micro Motion.
Liquid or moisture inside the housing Contact Micro Motion.
10.25 Locate a device using the HART 7 Squawk
feature
The Squawk feature causes the device to show a specific pattern on its display. You can use
this to locate or identify a device.
Restriction
The Squawk feature is available only with HART 7 connections. It is not available with ProLink III.
Procedure
1. Choose Service Tools > Maintenance.
2. Click Locate Device, then click Next.
An 0-0-0-0 pattern is shown on the display.
To return to the normal display, activate either Scroll or Select, or wait 60 seconds.
Troubleshooting
Configuration and Use Manual 159
