Emerson Micro Motion

Transmitter with end-cap removedFigure 7-1:
A
A. Transmitter end‐cap
3. Using the hex key, remove the safety spacer.
Transmitter with end-cap and safety spacer removedFigure 7-2:
A
B
A. Transmitter end‐cap
B. Safety spacer
4. Move the HART security switch to the ON position (down).
Completing the configuration
Configuration and Use Manual 101
