Bit(s) Name
0000b Unknown
0010b Faulted I/O Connection
0011b No I/O connection established
0100b Non-volatile configuration bad
0110b Connection in Run mode
0111b Connection in Idle mode
(other) (reserved)
8 Set for minor recoverable faults
9 Set for minor unrecoverable faults
10 Set for major recoverable faults
11 Set for major unrecoverable faults
12... 15 (reserved)
Reset service
When the Identity Object receives a Reset request, it:
• Determines if it can provide the type of reset requested
• Responds to the request
• Attempts to perform the type of reset requested
B.2.2
Message Router, Class 02h
The Message Router Object provides a messaging connection point through which a Client
may address a service to any object class or instance residing in the physical device.
B.2.3
Assembly Object, Class 04h
The Assembly Object binds attributes of multiple objects, which allows data to or from
each object to be sent or received over a single connection. Assembly objects can be used
to bind input data or output data. The terms “input” and “output” are defined from the
network's point of view. An input produces data on the network and an output consumes
data from the network.
This object provides access to the I/O Data in the Input and Output Data areas in the Micro
Motion EtherNet/IP Module.
Supported services
Class services: Get Attribute Single
Instance services:
• Get Attribute Single
User Guide
Device profile
MMI-20019808 January 2019
