• Set Attribute Single
Class attributes
# Access Name Type Value Description
1 Get Revision UINT 0002h Revision 2
2 Get Max Instance UINT - The highest initiated instance
number
Instance attributes - Instance/Connection Point 64h
This instance corresponds to I/O Data (Input) in the Micro Motion EtherNet/IP Module. The
EtherNet/IP Module supports two different configurations. Specific input assembly
attributes depend on the configuration in use.
Configuration Input assembly attributes
Basic See Input assembly for standard configuration
Concentration measurement See Input assembly for concentration measurement configuration
Note
The default input data size is non-zero. The actual size depends on the configuration in
use. If the I/O input data size is set to 0, this instance will NOT be initialized.
#
Access Name Type Value Description
3 Get Data Array of BYTE - Data produced by the Micro Motion
EtherNet/IP Module
Instance attributes - Instance/Connection Point 96h
This instance corresponds to I/O Data (Output) in the Micro Motion EtherNet/IP Module.
The EtherNet/IP Module supports two different configurations. Specific input assembly
attributes depend on the configuration in use.
Configuration
Output assembly attributes
Basic See Output assembly for standard configuration
Concentration measurement See Output assembly for concentration measurement configuration
Note
The default output data size is non-zero. The actual size depends on the configuration in
use. If the I/O output data size is set to 0, this instance will NOT be initialized.
#
Access Name Type Value Description
3 Set Data Array of BYTE - Data consumed by the Micro
Motion EtherNet/IP Module
Device profile User Guide
January 2019 MMI-20019808
38 Micro Motion EtherNet/IP Module
