# Access Name Type Description
02h Get Data Array of USINT Mapped block of Input Data
...
32h Get Data Array of USINT Mapped block of Input Data
The specific parameters in the block depend on the configuration in use.
Configuration Input parameters (explicit data)
Basic See Input parameters (explicit data) for standard configuration
Concentration measurement See Input parameters (explicit data) for concentration
measurement configuration
B.2.9 Parameter Data Output Mapping Object, Class B1h
This object can be used to access Output Data acyclically, and is set up dynamically (see
Output parameters (explicit data) for standard configuration).
Supported services
Class services: Get Attribute All
Instance services:
• Get Attribute Single
• Set Attribute Single
Class attributes
#
Access Name Type Value Description
1 Get Revision UINT 0001h Revision 1
Instance attributes, Instance 01h
#
Access Name Type Description
01h Get/Set Data Array of USINT Mapped block of Output Data
02h Get/Set Data Array of USINT Mapped block of Output Data
...
32h Get/Set Data Array of USINT Mapped block of Output Data
The specific parameters in the block depend on the configuration in use.
Configuration
Output parameters (explicit data)
Basic See Output parameters (explicit data) for standard configuration
User Guide Device profile
MMI-20019808 January 2019
User Guide 43

Emerson Micro Motion Specifications

General

Category	Measuring Instruments
Manufacturer	Emerson
Brand	Micro Motion
Type	Coriolis Flow Meter
Output	4-20 mA, HART, Foundation Fieldbus, Profibus, Modbus
Power Supply	24 V DC
Material	Stainless Steel, Hastelloy
Process Connection	Flanged, Threaded
Certifications	ATEX, IECEx, CSA, SIL
Pressure Rating	Varies by model; up to 10, 000 psi (690 bar)
Temperature Range	Varies by model; -400 to 750°F (-240 to 400°C)
