8.4 Resource block
8.4.1 PlantWeb Alerts
The PlantWeb Alerts (PWA) software supports three groups of alarms for three
severity levels: 1. Failed, 2. Maintenance, and 3. Advisory.
Each PWA can be configured for one or more of the three alarm groups. The PWA
alarms and their severity level default settings are listed in Table 8-2.
Table 8-2: Hazardous Area Rosemount OCX8800 PlantWeb Alerts
PlantWeb alert Severity level default
Reserved None
Sensor Malfunction Failed
Sensor Degraded Failed
Thermocouple Malfunction Failed
Sensor Heater Malfunction Failed
Sensor Heater Over Temperature Failed
Sensor Heater Temperature Variance Maintenance
Calibration Error Maintenance
Calibration Recommended Advisory
NV Memory Failure Failed
NV Writes Deferred Advisory
High Electronics Temperature Maintenance
ADC Failure Failed
Line Input Out of Range Advisory
Inter Board Comm Failure Failed
Simulate Active Advisory
Each alarm condition must be Enabled, Disabled, or have alarm reporting
Suppressed. The PWA alarms must be Enabled to allow the corresponding alarm
conditions to be detected. The PWA alarms can be Suppressed to mask out
failures from annunciation.
Sensor Malfunction
The Sensor Alerts tab displays one of the following alerts:
• O
2
Cell Open
• Comb Cell Error
This alert is active when the sensor is indicating a very high or unexpected output.
