C.4 Setup
To set up the SPA for communication with the transmitter, set internal jumpers
and dip switches and configure the SPA operating parameters via a menu-driven
selection and calibration procedure.
C.4.1 Jumper and switch settings
If the SPA with HART
®
was factory-configured by Emerson for operation with your
transmitter, jumper and switch setting adjustments are not required. However,
you may use the following procedure to verify that the jumper and switch settings
are correct. Adjust or verify jumper and switch settings as follows:
SPA jumper and switch settings are shown in Figure C-3.
CAUTION
Equipment damage
Protect the SPA from electrostatic discharge (ESD) to avoid damage to the SPA
electronic circuits.
Procedure
1. Refer to Figure C-3. Turn the SPA over and slide the access cover out.
SPA with HART
®
alarm Manual
December 2022 00809-0500-4880
320 Emerson.com/Rosemount
