Table 8-3: Transducer Block Parameter Descriptions
(continued)
Parameter mnemonic Valid range Units Description
O2_THERMOCOUPLE_INPUT N?A mV The raw value of the O
2
temperature input.
O2_TIME_TO_NEXT_CAL 0-9999 Hours The time until the next
automatic calibration of
the O
2
sensor.
O2_TOL_CHECK 0: No
1: Yes
N/A O
2
calibration gas
tolerance check.
OPERATING_MODE N/A Enumerated Device operating mode.
See Table 8-8.
PCD_COUNTER N/A N/A Power cycle drop
counter.
PCDC_ENABLE 0: No
1: Yes
N/A Enable/disable power
cycle drop detect.
PCN_COUNTER N/A N/A N/A
SB_HTR_DUTYCYCLE N/A N/A Sample block heater
duty cycle.
SB_SETPOINT N/A ° C Sample block heater
temperature set point.
SB_TEMP N/A ° C The temperature of the
sample line.
SB_TEMP_MAX N/A ° C The highest sample
block temperature read
since power on.
SB_THERMOCOUPLE_INPUT N/A mV The raw value of the
sample line temperature
input.
SENSOR_HOUSING_TEMP N/A ° C Sensor housing
temperature (valid only
with Type 3 sensor).
SENSOR_HOUSING_TEMP_I
NPUT
N/A mV Sensor housing CJC
voltage (valid only with
Type 3 sensor).
SENSOR_HOUSING_TEMP_
MAX
N/A ° C The highest sensor
housing temperature
read since power on.
SENSOR_HOUSING_TYPE 0, 1, 2, 3 Enumerated This is the sensor
housing type setting
through the DIP switch.
(0 = Type 1, 1 = Type 2, 2
= Type 3, 3 = Invalid)
Manual FOUNDATION
™
Fieldbus
00809-0500-4880 December 2022
Rosemount OCX8800A 137
