Table 8-25: PID Function Block System Parameters
(continued)
Parameter Index number Units Descriptions
GRANT_DENY 12 None Options for controlling
access of host computers
and local control panels
to operating, tuning, and
alarm parameters of the
block. This is not used by
the transmitter.
HI_ALM 61 None The HI alarm data, which
includes a value of the
alarm, a timestamp of
occurrence, and the state
of the alarm.
HI_HI_ALM 60 None The HI_HI alarm data,
which includes a value of
the alarm, a timestamp of
occurrence, and the state
of the alarm.
HI_HI_LIM 49 EU of PV_SCALE The setting for the alarm
limit used to detect the HI
HI alarm conditions.
HI_HI_PRI 48 None The priority of the HI HI
alarm.
HI_LIM 51 EU of PV_SCALE The setting for the alarm
limit used to detect the HI
alarm condition.
HI_PRI 50 None The priority of the HI
alarm.
IN 15 EU of PV_SCALE The connection for the PV
input from another block.
LO_ALM 62 None The LO alarm data, which
includes a value of the
alarm, a timestamp of
occurrence, and the state
of the alarm.
LO_LIM 53 EU of PV_SCALE The setting for the alarm
limit used to detect the
LO alarm conditions.
LO_LO_ALM 63 None The LO LO alarm data,
which includes a value of
the alarm, a timestamp of
occurrence, and the state
of the alarm.
LO_LO_LIM 55 EU of PV_SCALE The setting for the alarm
limit used to detect the
LO LO alarm condition.
FOUNDATION
™
Fieldbus Manual
December 2022 00809-0500-4880
172 Emerson.com/Rosemount
