Figure 1-4: Typical System Installation - Integral Electronics
A. Adapter plate
B. Signal outputs (twisted pairs)
C. Line voltage
D. Instrument air supply (reference gas)
E. High O
2
test gas
F. Low O
2
test gas
G. CO test gas
H. Gases
I. Duct
J. Stack
K. Test gas flow meter
L. Dilution air flow meter
M. Pressure regulator
