Figure 11-4: Electronics Housing Components for Rosemount OCX8800 with
Remote Electronics
Table 11-4: Electronics Housing Components for Rosemount OCX8800 with Remote Electronics
Index number Part number Description
1 1A97902H01 Hose
2 1A97905H02 Solenoid valve, 3-way
3 1A97905H01 Solenoid valve, test gas
4 6A00132G01 Electronics stack, HART
5 Special order Flash PROM, programmed
6 1A97913H06 Fuse (F1 and F6), 10 amp, 250 Vac
1A99766H01 Fuse (F3), 4 amp, 250 Vac
1A99766H02 Fuse (F4), 8 amp, 250 Vac
7 1A99089H02 Cover gasket (O-ring)
8 5R10219G01 Cover, blind
8A 5R10199G01 Cover, window
Replacement parts Manual
December 2022 00809-0500-4880
300 Emerson.com/Rosemount
