Unidrive SP Regen Installation Guide 185
Issue Number: 2 www.controltechniques.com
Table 10-3 Maximum permissible continuous output current @ 50°C (122°F) ambient for wall mounted drives
Model
Normal Duty
Heavy Duty
Nominal
rating
Maximum permissible continuous output current
(A) for the following switching frequencies
Nominal
rating
Maximum permissible continuous output current
(A) for the following switching frequencies
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz 3kHz 4kHz 6kHz 8kHz 12kHz 16kHzkW hp kW hp
SP1201 1.1 1.5 5.2 0.75 1.0 4.3
SP1202 1.5 2.0 6.8 1.1 1.5 5.8
SP1203 2.2 3.0 9.6 9.0 1.5 2.0 7.5
SP1204 3.0 3.0 11.0 10.9 9.5 8.3 2.2 3.0 10.6 9.5 8.3
SP2201 4.0 5.0 15.5 13.5 11.5 3.0 3.0 12.6 11.4
SP2202 5.5 7.5 19.7 18.9 17.3 15.9 13.5 11.5 4.0 5.0 17.0 15.7 13.4 11.4
SP2203 7.5 10 19.5 18.6 17.2 15.8 13.4 11.5 5.5 7.5 19.2 18.4 17.0 15.7 13.3 11.4
SP3201 11 15 42.0 38.2 7.5 10 31.0
SP3202 15 20 54.0 52.8 47.0 38.2 11 15 42.0 37.2
SP4201 18.5 25 68.0 15 20 56.0
SP4202 22 30 80.0 18.5 25 68.0
SP4203 30 40 87.4 22 30 80.0
SP5201 37 50 130 30 40 105
SP5202 45 60 154 37 50 130
SP1401 1.1 1.5 2.8 0.75 1.0 2.1
SP1402 1.5 2.0 3.8 1.1 2.0 3.0
SP1403 2.2 3.0 5.0 3.9 1.5 3.0 4.2 3.8
SP1404 3.0 5.0 6.9 5.1 3.9 2.2 3.0 5.8 4.8 3.7
SP1405 4.0 5.0 8.8 7.3 6.0 4.2 3.1 3.0 5.0 7.6 7.2 6.0 4.2 3.1
SP1406 5.5 7.5 10.1 9.0 7.3 6.0 4.2 3.1 4.0 5.0 9.5 9.0 7.2 6.0 4.2 3.1
SP2401 7.5 10 15.3 14.2 11.8 10.0 7.3 5.5 5.5 10 13.0 11.7 9.9 7.3 5.5
SP2402 11 15 15.7 14.2 11.8 10.0 7.3 5.5 7.5 10 15.5 14.1 11.7 9.9 7.3 5.5
SP2403 15 20 16.8 15.0 12.2 10.1 7.1 11 20 16.7 15.0 12.2 10.1 7.1 5.1
SP2404* 15 20 22.3 19.8 15.8 12.8 8.6 5.9 15 20 22.3 19.8 14.0 11.2 7.3 4.6
SP3401 18.5 25 35.0 33.5 28.5 21.5 16.9 15 25 32.0 30.7 26.1 19.7 15.4
SP3402 22 30 43.0 41.5 34.2 28.7 21.0 16.0 18.5 30 40.0 34.1 28.4 20.7 16.0
SP3403 30 40 46.0 41.5 34.2 28.7 21.0 22 30 46.0 41.5 33.6 28.3 20.8
SP4401 37 50 68.0 66.8 54.9 30 50 60.0 46.7 38.3
SP4402 45 60 83.0 81.6 66.5 52.3 37 60 68.2 58.6 46.0 37.7
SP4403 55 75 86.5 86.2 71.3 59.3 45 75 86.5 74.7 60.1 49.8
SP5401 75 100 138 105.9 87.4 55 100 112.7 96.4 74.5 59.9
SP5402 90 125 141 140 112 92 75 125 140 123 99.0 82.0
SP6401 110 150 191.5 190.1 147.6 90 150 180 157.9 121.5
SP6402 132 200 198.4 180.6 138.1 110 150 190 157.9 116.2
SP3501 3.0 3.0 5.4 2.2 2.0 4.1
SP3502 4.0 5.0 6.1 3.0 3.0 5.4
SP3503 5.5 7.5 8.4 4.0 5.0 6.1
SP3504 7.5 10 11.0 5.5 7.5 9.5
SP3505 11 15 16.0 14.7 7.5 10 12.0
SP3506 15 20 22.0 17.8 14.7 11 15 18.0 16.8 13.9
SP3507 18.5 25 24.6 22.0 17.8 14.7 15 20 22.0 20.4 16.7 13.9
SP4601 18.5 25 22.0 15 20 19.0
SP4602 22 30 27.0 24.7 18.5 25 22.0
SP4603 30 40 36.0 30.7 24.7 22 30 27.0
SP4604 37 50 43.0 39.6 30.7 24.7 30 40 36.0 30.7 24.7
SP4605 45 60 45.6 39.5 30.7 24.7 37 50 43.0 39.6 30.7 24.7
SP4606 55 75 51.9 44.9 34.7 27.7 45 60 51.9 44.9 34.7 27.7
SP5601 75 100 83 69 51 40 55 75 63 63 47 38
SP5602 90 125 83 69 51 40 75 100 75 62 45 36
SP6601 110 150 98 81 59 90 125 98 81 59
SP6602 132 175 98 81 59 110 150 98 81 59
