Unidrive SP Regen Installation Guide 55
Issue Number: 2 www.controltechniques.com
5.4 External EMC filter
Table 5-10 Drive EMC filter details (size 1 to 6)
In order to provide our customers with a degree of flexibility, external
EMC filters have been sourced from two manufacturers: Schaffner &
Epcos.
Filter details for each drive rating are provided in the tables below. Both
the Schaffner and Epcos filters meet the same specifications.
Table 5-11 Drive EMC filter details
In order to provide our customers with a degree of flexibility, external EMC filters have been sourced from two manufacturers: Schaffner & Epcos.
Filter details for each drive rating are provided in the tables below. Both the Schaffner and Epcos filters meet the same specifications.
Drive
Schaffner Epcos
CT part no. Weight CT part no. Weight
SP1201 to SP1204
4200-6118
1.4 kg (3.1 lb)
4200-6121
2.1 kg (4.6 lb)
4200-6119 4200-6120
SP2201 to SP2203 4200-6210 2.0 kg (4.4 lb) 4200-6211 3.3 kg (7.3 lb)
SP3201 to SP3202 4200-6307 3.5 kg (7.7 lb) 4200-6306 5.1 kg (11.2 lb)
SP4201 to SP4203 4200-6406 4.0 kg (8.8 lb) 4200-6405 7.8 kg (17.2 lb)
SP5201 to SP5202 4200-6503 6.8 kg (15.0 lb) 4200-6501 12.0 kg (26.5 lb)
SP1401 to SP1404 4200-6118
1.4 kg (3.1 lb)
4200-6121
2.1 kg (4.6 lb)
SP1405 to SP1406 4200-6119 4200-6120
SP2401 to SP2404 4200-6210 2.0 kg (4.4 lb) 4200-6211 3.3 kg (7.3 lb)
SP3401 to SP3403 4200-6305 3.5 kg (7.7 lb) 4200-6306 5.1 kg (11.2 lb)
SP4401 to SP4403 4200-6406 4.0 kg (8.8 lb) 4200-6405 7.8 kg (17.2 lb)
SP5401 to SP5402 4200-6503 6.8 kg (15.0 lb) 4200-6501 12.0 kg (26.5 lb)
SP6401 to SP6402 4200-6603 5.25 kg (11.6 lb) 4200-6601 10.0 kg (22.0 lb)
SP3501 to SP3507 4200-6309 3.5 kg (7.7 lb) 4200-6308 5.1 kg (11.2 lb)
SP4601 to SP4606 4200-6408 3.8 kg (8.4 lb) 4200-6407 8.0 kg (17.6 lb)
SP5601 to SP5602 4200-6504 4.4 kg (9.7 lb) 4200-6502 10.0 kg (22.0 lb)
SP6601 to SP6602 4200-6604 5.25 kg (11.6 lb) 4200-6602 8.6 kg (18.9 Ib)
Drive
Schaffner Epcos
CT part no. Weight CT part no. Weight
SPMD1201 to
SPMD1204
4200-6315
5.5 kg
(12.1 Ib)
4200-6313
8.6 kg
(18.9 Ib)
SPMA1401 to
SPMA1402
4200-6603
5.25 kg
(11.6 lb)
4200-6601
10.0 kg
(22.0 Ib)
SPMD1401 to
SPMD1404
4200-6315
5.5 kg
(12.1 Ib)
4200-6313
8.6 kg
(18.9 Ib)
SPMD1601 to
SPMD1602
4200-6604
5.25 kg
(11.6 lb)
4200-6602
8.6 kg
(18.9 Ib)
SPMD1601 to
SPMD1604
4200-6316
5.5 kg
(12.1 Ib)
4200-6314
8.5 kg
(18.7 Ib)
