SLX.dF Solutions Module slot X trip: Solutions Module type fitted in slot X changed
204,209,214 Save parameters and reset
SLX.Er Solutions Module slot X trip: Solutions Module in slot X has detected a fault
202,207,212
Automation module category
Check value in Pr 15/16/17.50. The following table lists the possible error codes for the SM-Applications and SM-Applications Lite.
Check value in Pr 15/16/17.50. The following table lists the possible error codes for the I/O module.
Trip Diagnosis
Error code Reason for fault
39 User stack overflow
40 Unknown error
41 Parameter does not exist
42 Parameter read only
43 Parameter write only
44 Parameter value over range
45 Invalid synchronisation modes
46 Not Used
47 Sync lost with Virtual Master
48 RS485 not in user mode
49 Invalid RS485 configuration
50 Math fault
51 Array index out of range
52 Control word user trip
53 DPL program not compatible with this target
54 Processor overload/ Task Overrun
55 Invalid encoder configuration
56 Invalid timer unit configuration
57 Function block not supported by system
58 Corrupted Non-volatile flash
59 Drive rejected application module as Sync master
60 CTNet hardware error
61 Invalid CTNet configuration
62 CTNet baud rate does not match network
63 CTNet node ID already in use
64 Digital Output Overload
65 Invalid Function Block parameters
66 User Heap Requirement too large
67 File Does Not Exist
68 File Not Associated
69 Flash Access Failed during DB upload from drive
70 User Program download while drive enabled
71 Failed to change drive mode
72 Invalid CTNet Buffer Operation
73 Fast Parameter Initialisation Failure
74 Solutions Module over temperature
Error code Reason for fault
0 No errors
1 Digital output short circuit
74 Module over temperature
