Parameter value Parameter string Mode Comments
0 0-20 0 - 20mA
1 20-0 20 - 0mA
2 4-20.tr 4 -20mA with trip on loss Trip if I < 3mA
3 20-4.tr 20 - 4mA with trip on loss Trip if I < 3mA
4 4-20 4 - 20mA with no trip on loss
5 20-4 20 - 4mA with no trip on loss 0.0% if I < 4mA
6 VOLt Voltage mode
7 th.SC Thermistor with short circuit detection
TH trip if R > 3k3
TH reset if R < 1k8
THS trip if R < 50R
8 th Thermistor without short circuit detection
TH trip if R > 3k3
TH reset if R < 1k8
9 th.diSp Thermistor display only with no trip
7.16 T8 analogue input 3 scaling
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
3111
Range Regen 0.000 to 4.000
Default Regen 1.000
Update rate Background
7.17 T8 analogue input 3 invert
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Default Regen 0
Update rate Background
7.18 T8 analogue input 3 destination
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1 2 1111
Range Regen Pr 0.00 to Pr 21.51
Default Regen Pr 0.00
Update rate Background
7.19 T9 analogue output 1 source
Drive mode Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
21111
Range Regen Pr 0.00 to Pr 21.51
Default Regen Pr 4.01
Update rate Background
