Table 3-19 690V (690V ± 10%) SFF Inductor
The inductors are standard three phase inductors (rated at Unidrive SP
Regen drive rated current). They carry only 50/60Hz current with a
negligible amount of high frequency current. The above switching
frequency filter inductors are calculated at 4% of the regen drives rating
using the following formula. A tolerance can be applied to the calculated
value in the range of, -10% to +30%.
L switching frequency filter mH = VLL / √3 x 1 / Irated x 0.04 x 1 / (2 x pi
x f).
Where:
VLL = Supply voltage line-to-line
f = Supply frequency
Irated = Drive rated current
This calculation also gives the correct inductance value for a 480V, 60Hz
supply.
Table 3-20 200V (200V to 240V ± 10%) SFF Capacitors
Table 3-21 400V (380V to 480V ± 10%) SFF Capacitors
Table 3-22 575V (500V to 575V ± 10%) SFF Capacitors
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP4601 SP4601 4401-1211 1.40 22.0
SP4602
4401-1211 1.40 22.0
SP4603 SP4602 4401-1213 1.40 36.0
SP4604 SP4603 4401-1213 1.40 36.0
SP4605 SP4604 4401-1214 1.20 43.0
SP4606 SP4605 4401-1215 1.00 52.0
SP5601 SP4606 4401-1216 0.80 63.0
SP5602 SP5601 4401-1217 0.60 85.0
SP6601 SP5602 4401-1218 0.50 100.0
SP6602 SP6601 4401-1219 0.40 125.0
SPMA1601
4401-1218 0.50 100.0
SPMD1601
4401-1218 0.50 100.0
SPMA1602 SPMA1601 4401-1219 0.40 125.0
SPMD1602 SPMD1601 4401-1219 0.40 125.0
SPMA1602 4401-1220 0.35 144.0
SPMD1602 4401-1220 0.35 144.0
SPMD1603 SP6602 4401-1220 0.35 144.0
SPMD1604 SPMD1603 4401-1221 0.30 168.0
SPMD1604 4401-1222 0.26 192.0
Drive
Part number uF Arms
Heavy Duty Normal Duty
SP1203 SP1203
1664-1074 7 1.7SP1204 SP1204
SP2201 SP2201
SP2202 SP2202
1664-2174 16.6 4.3
SP2203 SP2203
SP3201 SP3201
SP3202
SP4201 SP3202
1665-8324 32 11SP4202 SP4201
SP4203 SP4202
SP5201 SP4203
1664-2644 64 17SP5202 SP5201
SPMD1201 SP5202
SPMD1202 SPMD1201
2 x 1664-2644 2 x 64 2 x 17
SPMD1203 SPMD1202
SPMD1204 SPMD1203
SPMD1204
NOTE
Drive
Part number uF Arms
Heavy Duty Normal Duty
SP1405 SP1405
1610-7804 8 4.3
SP1406 SP1406
SP2401 SP2401
SP2402 SP2402
SP2403
SP2404 SP2403
1665-8324 32 11
SP3401 SP2404
SP3402 SP3401
SP3403 SP3402
SP4401 SP3403
SP4401
SP4402 SP4402
1665-8484 48 17
SP4403 SP4403
SP5401 SP5401
SP5402 SP5402
SP6401 SP6401
SP6402
SPMA1401 SPMA1401
SPMA1402
SPMD1401 SPMD1401
SPMD1402
SP6402
1665-8774 77 26
SPMA1402 SPMA1402
SPMD1402
SPMD1403 SPMD1403
SPMD1404
SPMD1404 2 x 1665-8394 2 x 39 2 x 13
Drive
Part number uF Arms
Heavy Duty Normal Duty
SP3505 SP3505
1666-8113 11.2 5
SP3506 SP3506
SP3507 SP3507
SP4601 SP4601
SP4602 SP4602
SP4603 SP4603
SP4604 SP4604
SP4605 SP4605
SP4606 SP4606
SP5601 SP5601
SP5602
SP6601 SP5602
1666-8223 22.5 10
SP6602 SP6601
SPMA1601 SP6602
SPMA1602 SPMA1601
SPMD1601 SPMA1602
SPMD1602 SPMD1601
SPMD1603 SPMD1602
SPMD1604 SPMD1603
2 x 1666-8233
2 x
22.5
2 x 10
SPMD1604
