54 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
Figure 5-15 3-phase Polecap dimensions Figure 5-16 3-phase Windcap / Phasecap dimensions
Terminal cover
(uv resistant)
Label
L
∅
81.2 0.3mm ±
Mxx
Torqu e = Nm
16.0 0.1mm ±
210mm max.
Cable gland
Ø22mm
18mm
Marking
16 +1mm
Mxx
Torque
T=Nm
Impregnating
Hole
Torqu e
T=1.2Nm
SW 17mm
L
∅
19.6 0.5mm ±
16.8 0.5mm ±
