26 Unidrive SP Regen Installation Guide
www.controltechniques.com Issue Number: 2
Table 3-15 690V (690V ± 10%) Regen Inductor
3.10.2 Switching frequency filter
These components are used to form the filter, preventing switching
frequency harmonic currents getting back onto the supply. If the filter is
not fitted, the presence of currents in the kHz region could cause supply
problems or disturbance to other equipment.
Table 3-16 200V (200V to 240V ± 10%) SFF Inductors
Table 3-17 400V (380V to 480V ± 10%) SFF Inductor
Table 3-18 575V (500V to 575V ± 10%) SFF Inductor
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP4601
4401-0210 5.30 19.0
SP4602 SP4601 4401-0211 4.60 22.0
SP4603 SP4602 4401-0212 3.80 27.0
SP4604 SP4603 4401-0213 2.80 36.0
SP4605 SP4604 4401-0214 2.40 43.0
SP4606 SP4605 4401-0215 1.90 52.0
SP5601 SP4606 4401-0216 1.60 63.0
SP5602 SP5601 4401-0217 1.20 85.0
SP6601 SP5602 4401-0218 1.00 100.0
SP6602 SP6601 4401-0219 0.80 125.0
SPMA1601
4401-0218 1.00 100.0
SPMD1601
4401-0218 1.00 100.0
SPMA1602 SPMA1601 4401-0219 0.80 125.0
SPMD1602 SPMD1601 4401-0219 0.80 125.0
SPMA1602 4401-0220 0.70 144.0
SPMD1602 4401-0220 0.70 144.0
SPMD1603 SP6602 4401-0220 0.70 144.0
SPMD1604 SPMD1603 4401-0221 0.60 168.0
SPMD1604 4401-0222 0.53 192.0
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP1203 SP1203 4401-1310 0.88 9.6
SP1204 SP1204 4401-1311 1.50 11.0
SP2201 SP2201 4401-1312 1.10 15.5
SP2202 SP2202 4401-1313 0.70 22.0
SP2203 SP2203 4401-1314 0.50 31.0
SP3201
4401-1314 0.50 31.0
SP3202 SP3201 4401-1315 0.40 42.0
SP4201 SP3202 4401-1316 0.30 56.0
SP4202 SP4201 4401-1317 0.25 68.0
SP4203 SP4202 4401-1318 0.20 80.0
SP5201 SP4203 4401-1319 0.16 105.0
SP5202 SP5201 4401-1320 0.13 130.0
SPMD1201 SP5202 4401-1321 0.11 156.0
SPMD1202 SPMD1201 4401-1322 0.088 192.0
SPMD1203 SPMD1202 4401-1323 0.068 250.0
SPMD1204 SPMD1203 4401-1324 0.055 312.0
SPMD1204 4401-1325 0.048 350.0
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP1405 SP1405 4401-0162 3.16 9.5
SP1406
4401-0162 3.16 9.5
SP1406 4401-0163 2.50 12.0
SP2401 SP2401 4401-0164 1.875 16.0
SP2402 SP2402 4401-0165 1.20 25.0
SP2403
4401-0165 1.20 25.0
SP2404 SP2403 4401-0166 0.88 34.0
SP3401 SP2404 4401-0166 0.88 34.0
SP3402 SP3401 4401-0167 0.75 40.0
SP3403 SP3402 4401-0168 0.65 46.0
SP4401 SP3403 4401-0169 0.50 60.0
SP4401 4401-0170 0.39 70.0
SP4402 SP4402 4401-0171 0.315 96.0
SP4403
4401-0171 0.315 96.0
SP5401 SP4403 4401-0172 0.24 124.0
SP5402 SP5401 4401-0173 0.19 156.0
SP6401 SP5402 4401-0174 0.165 180.0
SP6402 SP6401 4401-0175 0.135 220.0
SP6402 4401-0176 0.10 300.0
SPMA1401
4401-0174 0.165 180.0
SPMA1402 SPMA1401 4401-0175 0.135 220.0
SPMA1402 4401-0176 0.10 300.0
SPMD1401
4401-0174 0.165 180.0
SPMD1402 SPMD1401 4401-0175 0.135 220.0
SPMD1403 SPMD1402 4401-0176 0.10 300.0
SPMD1404 SPMD1403 4401-0176 0.10 300.0
SPMD1404 4401-1205 0.08 350.0
Drive
Part number mH Arms
Heavy Duty Normal Duty
SP3505 SP3505 4401-1211 1.40 22.0
SP3506
4401-1211 1.40 22.0
SP3506 4401-1213 1.40 36.0
SP3507 SP3507 4401-1213 1.40 36.0
SP4601 SP4601 4401-1211 1.40 22.0
SP4602
4401-1211 1.40 22.0
SP4603 SP4602 4401-1213 1.40 36.0
SP4604 SP4603 4401-1214 1.20 43.0
SP4605 SP4604 4401-1215 1.00 52.0
SP4606 SP4605 4401-1216 0.80 63.0
SP5601 SP4606 4401-1217 0.60 85.0
SP5602 SP5601 4401-1218 0.50 100.0
SP6601 SP5602 4401-1219 0.40 125.0
SP6602 SP6601 4401-1220 0.35 144.0
SPMA1601
4401-1219 0.40 125.0
SPMD1601
4401-1219 0.40 125.0
SPMA1602 SPMA1601 4401-1220 0.35 144.0
SPMD1602 SPMD1601 4401-1220 0.35 144.0
SPMA1602 4401-1221 0.30 168.0
SPMD1602 4401-1221 0.30 168.0
SPMD1603 SP6602 4401-1221 0.30 168.0
SPMD1604 SPMD1603 4401-1222 0.26 192.0
SPMD1604 4401-1223 0.21 192.0
