(10) Analog output status for inverter for fan: it’s present only if an inverter for fan is used. It
displays the percentage of the analog output driving the inverter.
Not present if the “free” analog output is used.
(11) Status of the delivery section:
The condenser pressure (temperature) is below the regulation band and the number of
fans is decreasing
The condenser pressure (temperature) is above the regulation band and the number
of fans is increasing
(12) Number of fans activated / Total number of fans it’s present for the following
configuration of the parameter C0.
C0: 0A1D; 1A1D, 0A2D, 1A2D, “2A2D
NOTE: the total number of fans is referred to the number of available fans. Fans that are in
“maintenance” or that are stopped by their own digital input aren’t included.
(13) Symbol of fan: it’s present for the following configuration of the parameter C0.
C0: 0A1D; 1A1D, 0A2D, 1A2D, “2A2D
(14) Number of compressors and steps activated / Total number of compressors and
steps. it’s present for the following configuration of the parameter C0.
C0 = 1A0D; 1A1D, 2A0D, 2A1D, 2A2D
NOTE: the total number of compressors is referred to the number of available compressors.
Compressors that are in “maintenance” or that are stopped by their own digital input aren’t
included.
Keys
Alarm: to enter the alarm menu
Parameter: to enter the parameter programming
Service: to enter the Service menu
Measurement unit: to switch the probe visualization and set point from pressure to
temperature and vice versa
To switch the controller off: hold pushed for 10s to switch the controller off (it’s
enabled only if the parameter OT9 = yES)
Energy saving: hold pushed for 10s to enable the energy saving cycle (the SET label
starts flashing)
Circuit 2: to pass to visualization of the variables of the second circuit, It’s present for
the following configuration of the parameter C0: 0A2D; 2A0D, 2A2D.
