1592021021 XC1008-1011-1015D GB A5 r.1.5A 12.10.2009 XC1008-1011-1015D 27/66
CINT: °C with decimal point (bar);
F: °F (PSI);
BAR: bar (°C);
PSI: PSI (°F);
KPA: KPA (°C)
CKPA: °C (KPA)
NOTE1: changing the measurement unit, the instrument will update parameter values that refer to
pressure or temperature.
NOTE2: parameters with probe calibration, are reset during the measurement unit change.
C46 Pressure display: it indicates if the range of the probes are related to relative or absolute pressure.
rEL = relative pressure; AbS: absolute pressure
NOTE: the temperature is updated changing this value.
6.1.4 Analog Inputs (Ai1-Ai15)
AI1 Kind of probe of P1 & P2: it sets the kind of probes for suction sections: Cur = 4 ÷ 20 mA probe;
Ptc = Ptc probe; ntc = NTC probe; rAt = rathiometric probe (0÷5V).
AI2 Adjustment of read out for the probe 1 at 4mA/0V: (-1.00 ÷ AI3 bar; -15 ÷ AI3 PSI, -100 ÷ AI3
KPA)
;
AI3 Adjustment of read out for the probe 1 at 20mA/5V: (AI2 ÷ 100.00 bar; AI2 ÷ 750 PSI; AI2 ÷
10000 KPA)
AI4 Probe 1 calibration:
with C45 = CDEC or CINT: -12.0 ÷ 12.0 °C
with C45= bar: -1.20 ÷ 1.20 bar;
with C45 = F or PSI: -120 ÷ 120 °F o PSI
with C45 = KPA: -1200 ÷ 1200 KPA;
AI5 Adjustment of read out for the probe 2 at 4mA/0V: (-1.00 ÷ AI6bar; -15 ÷ AI6 PSI)
AI6 Adjustment of read out for the probe 2 at 20mA/5V: (AI5 ÷ 51.00 bar; AI5 ÷ 750 PSI)
AI7 Probe 2 calibration:
with C43 = CEL_DEC or CEL_INT: -12.0 ÷ 12.0 °C
with C43 = bar: -1.20 ÷ 1.20 bar;
with C43 = FAR or PSI: -120 ÷ 120 °F or PSI
AI8 Kind of probe of P3 & P4: : it sets the kind of probes for delivery sections: Cur = 4 ÷ 20 mA probe;
Ptc = Ptc probe; ntc = NTC probe; rAt = rathiometric probe (0÷5V).
AI9 Adjustment of read out for the probe 3 at 4mA/0V: (-1.00 ÷ AI10bar; -15 ÷ AI10 PSI; -100 ÷ AI10
KPA)
AI10 Adjustment of read out for the probe 3 at 20mA/5V: (AI9 ÷ 100.00 bar; AI9 ÷ 750 PSI; AI9 ÷
10000 KPA)
AI11 Probe 3 calibration
with C45 = CDEC or CINT: -12.0 ÷ 12.0 °C
with C45 = bar: -1.20 ÷ 1.20 bar;
with C45 = F or PSI: -120 ÷ 120 °F o PSI
with C45 = KPA: -1200 ÷ 1200 KPA;
AI12 Adjustment of read out for the probe 4 at 4mA/0V: (-1.00 ÷ AI13bar; -15 ÷ AI13 PSI; -100 ÷ AI13
KPA)
AI13 Adjustment of read out for the probe 4 at 20mA/5V: (AI12 ÷ 100.00 bar; AI12 ÷ 750 PSI; AI12 ÷
10000 KPA)
AI14 Probe 4 calibration:
with C45 = CDEC or CINT: -12.0 ÷ 12.0 °C
with C45 = bar: -1.20 ÷ 1.20 bar;
with C45 = F or PSI: -120 ÷ 120 °F o PSI
with C45 = KPA: -1200 ÷ 1200 KPA;
AI15 Alarm activated in case of regulation faulty probe:
nu = none relay; Alr: all the C(i) outputs set as ALr; ALr1: all the C(i) outputs set as ALr1, ALr2: all
the C(i) outputs set as ALr2
6.1.5 Auxiliary analog inputs (Ai1-Ai15)
AI16 Probe 1 AUX setting: ptc = PTC probe; ntc= NTC probe
AI17 Probe 1 AUX action type: it sets the function ot the AUX1 probe (term. 70-71)
