1592021021 XC1008-1011-1015D GB A5 r.1.5A 12.10.2009 XC1008-1011-1015D 2/66
INDEX
1. GENERAL WARNING 4
1.1 PLEASE READ BEFORE USING THIS MANUAL 4
1.2
SAFETY PRECAUTIONS 4
2. WIRING CONNECTIONS 5
2.1 XC1008D 5
2.2 XC1011D 6
2.3 XC1015D 7
2.4 DESCRIPTIONS OF THE WIRING CONNECTIONS 7
3. USER INTERFACE 9
3.1 WHAT IS DISPLAYED WHEN THE KEYBOARD IS CONNECTED 9
3.2 DISPLAY VISUALIZATION 10
3.3 PROGRAMMING 12
4. SERVICE MENU 15
4.1 HOW TO ENTER THE SERVICE MENU 15
4.2 HOW TO PROGRAM AN INSTRUMENT USING A HOT KEY 16
4.3 HOW TO SEE THE VALUES OF ANALOG OUTPUTS 16
4.4 HOW TO SEE THE STATUS OF THE RELAYS 17
4.5 COMPRESSOR SERVICE SUB- MENU – FOR MAINTENANCE SECTIONS 17
4.6 HOW TO SEE THE STATUS OF DIGITAL INPUTS 19
4.7 HOW TO SEE THE VALUES OF THE PROBES 20
4.8 HOW TO SET TIME AND DATE 20
5. ALARMS 21
5.1 MENU ACTIVE ALARMS 21
5.2 ACTIVE ALARM LOG MENU 22
5.3 ACTIVE ALARM LOG MENU 23
6. PARAMETERS 23
7. REGULATION 42
7.1 NEUTRAL ZONE ADJUSTMENT – ONLY FOR COMPRESSORS 42
7.2 PROPORTIONAL BAND ADJUSTMENT – FOR COMPRESSORS AND FANS 43
8. SCREW COMPRESSORS 45
8.1 REGULATION WITH SCREW COMPRESSORS LIKE BITZER/ HANBELL/ REFCOMP ETC 45
8.2 REGULATION WITH SCREW COMPRESSORS LIKE FRASCOLD 45
9. ANALOG OUTPUTS FOR INVERTER 47
9.1 COMPRESSOR MANAGEMENT 47
