16. Default setting
Nome XC
1008
D
XC
1011
D
XC
1015
D
Level
Description Range
SETC1
-18.0 -18,0 -18,0 Pr1 Compressor set point circuit 1
SETF1
35.0 35,0 35,0 Pr1 Fan set point circuit 1
SETC2
-18.0 -18,0 -18,0 Pr1 Compressor set point circuit 2
SETF2
35.0 35,0 35,0 Pr1 Fan set point circuit 2
C0
1A1d 1A1D 1A1D Pr2 Kind of plant 0A1d(0) - 1A0d(1) - 1A1d(2) - 0A2d(3) -
2A0d(4) - 2A1d(5) - 2A2d(6)
C1
CPr1 CPr1 CPr1 Pr2 Relay 1 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C2
CPr1 CPr1 CPr1 Pr2 Relay 2 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C3
CPr1 CPr1 CPr1 Pr2 Relay 3 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C4
CPr1 CPr1 CPr1 Pr2 Relay 4 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C5
Fan1 CPr1 CPr1 Pr2 Relay 5 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C6
Fan1 Fan1 Fan1 Pr2 Relay 6 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C7
Fan1 Fan1 Fan1 Pr2 Relay 7 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C8
Fan1 Fan1 Fan1 Pr2 Relay 8 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C9
- Fan1 Fan1 Pr2 Relay 9 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C10
- Fan1 Fan1 Pr2 Relay 10 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C11
- FAn1 nu Pr2 Relay 11 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C12
- - nu Pr2 Relay 12 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C13
- - nu Pr2 Relay 13 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C14
- - nu Pr2 Relay 14 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C15
- - nu Pr2 Relay 15 configuration Frq1; Frq2; CPr1; CPr2; StP; Frq1F; Frq2F;
FAn1; FAn2; Alr; ALr1; ALr2; AUS1; AUS2;
AUS3; AUS4; onF; nu
C16
SPo SPo SPo Pr2 Kind of compressors SPo(0) - dPo(1)
C17
CL cL cL Pr2 Valve polarity circuit 1 OP - CL
C18
- cL cL Pr2 Valve polarity circuit 2 OP - CL
