Winding the
bobbin
S
P
Bobbin winding
1. Place the thread and spool holder onto the spool pin.
For smaller spools of thread, place spool holder with the small
side next to the spool or use the small spool holder.
2. Snap the thread into the thread guide.
3. Wind the thread contrary clockwise around the bobbin winder
tension discs.
4. Place the thread end through one of the inner holes in the bobbin
as illustrated and place empty bobbin on the spindle.
5. Push the bobbin to the right.
6. When the bobbin winder shaft is pushed to the right, the digital
display screen will blink on and off while displaying "
SP
".
7. Hold the thread tail securely in one hand.
8. Press on the foot control to start winding the bobbin.
9. After the bobbin has wound a few turns stop the machine and cut
the thread near the hole of the bobbin. Continue filling the bobbin
until it is full. The motor stops automatically when the bobbin is
full. Stop the machine. Push the bobbin winder spindle to left.
10. Cut the thread and then remove the bobbin.
Please Note: When the bobbin winder switch is placed on the right, "bobbin winding position", the
machine will not sew and the hand wheel will not turn. To start sewing, push the bobbin winder switch
to the left "sewing position".
